Neurosoft Neuro-Audio

Questions and Answers

C
Cindy EvansAug 17, 2025
What to do if I get a USB transfer error message on Neurosoft Diagnostic Equipment?
- E
  Erin LewisAug 17, 2025
  If you see the message “USB transfer error. Check the connection and restart the system” on your Neurosoft Diagnostic Equipment, it means the system either disconnected during recording or failed during USB data exchange. To fix this, check the connection of the Neuro-Audio digital system and restart the signal recording. If the problem persists, restart your computer.
B
brennankatherineAug 20, 2025
What to do if Neurosoft Neuro-Audio shows a timeout error?
- A
  Anthony WalkerAug 20, 2025
  If the Neurosoft Diagnostic Equipment displays the message “Timeout error. The device does not transfer data”, this indicates an equipment error. To resolve this, restart the signal recording. If the problem continues, restart your computer.
J
jordankathyAug 23, 2025
What to do if Neurosoft Diagnostic Equipment says Neuro-Audio is already in use?
- W
  Wanda ColemanAug 23, 2025
  If your Neurosoft Diagnostic Equipment shows the message “Neuro-Audio is already used by other program”, it means another program is using the Neuro-Audio digital system. Close any other programs using the Neuro-Audio system. If you can’t find such a program, restart the computer.
O
oortizAug 26, 2025
How to fix 'Program supported devices are not found' error on Neurosoft Neuro-Audio Diagnostic Equipment?
- M
  matthewguzmanAug 26, 2025
  If you receive the message “Program supported devices are not found” on your Neurosoft Diagnostic Equipment, it means the electronic unit of the Neuro-Audio digital system is not connected to your PC. Check the connection of the electronic unit to the PC. If there are no connection errors, disconnect the electronic unit and reconnect it after a few seconds. If it still doesn’t work, restart the computer.
M
Michael RodriguezAug 28, 2025
What causes 'Link error: Neuro-Audio is not connected or defective' on Neurosoft Diagnostic Equipment?
- A
  Amy HillAug 28, 2025
  If you see the message “Link error: Neuro-Audio is not connected or defective” on your Neurosoft Diagnostic Equipment, it indicates that the electronic unit of the Neuro-Audio digital system is not connected to the PC. Check the connection of the electronic unit to the PC. If there are no connection errors, disconnect the electronic unit from the computer and reconnect it after a few seconds. If the issue continues, restart the computer.
C
Clifford BlackwellAug 31, 2025
How to resolve Neuro-Audio shutdown error on Neurosoft Diagnostic Equipment?
- W
  williamsravenAug 31, 2025
  If the Neurosoft Diagnostic Equipment displays “Neuro-Audio shutdown error. Close program, disconnect the system from PC and then connect it again”, it indicates a failure to properly shut down the electronic unit. Close the operating program, disconnect the electronic unit from the PC (USB hub), and then reconnect it. If the problem persists, restart the computer.
D
Deborah NelsonSep 2, 2025
What does 'Processing error. The system is overloaded' mean on Neurosoft Neuro-Audio Diagnostic Equipment?
- J
  John ThompsonSep 2, 2025
  If your Neurosoft Diagnostic Equipment displays the message “Processing error. The system is overloaded. Please, restart”, it means that the processor was overloaded and failed to receive data from the system. Close all applications except the Neuro-Audio.NET program (if they are running) and restart the recording. If it doesn't work, restart the computer. If the trouble does not disappear, then, probably, the processing speed of your PC is not enough. The minimal requirements for PC are given in the user manual.
J
John AlexanderSep 5, 2025
Why is there high supply-line noise in the signal recorded by Neurosoft Diagnostic Equipment?
- P
  patriciaroweSep 5, 2025
  If you experience high supply-line noise in the recorded signal (frequency – 50 (60) Hz or divisible) when using the Neurosoft Diagnostic Equipment, it could be due to several reasons: * Unused electrodes connected to the amplifier. * Improperly placed electrodes. * Bad grounding of the system. * Presence of powerful noise sources. To solve this: 1. Disconnect unused electrodes from the amplifier. 2. Measure impedance and ensure accepted values, replacing defective electrodes. 3. Ensure the computer is safely grounded. 4. Remove or move noise sources away and improve system grounding.
R
Ryan CooperSep 8, 2025
What to do if there is no stimulus when recording with Neurosoft Neuro-Audio Diagnostic Equipment?
- K
  kfisherSep 8, 2025
  If there is no stimulus when recording starts on your Neurosoft Diagnostic Equipment, it may be because the stimulation device (OAE probe, headphones, etc.) is not properly connected to the stimulator unit or the connection between the stimulator and PC is broken. Ensure the stimulation device is correctly connected to the stimulator unit. If the issue persists, execute the Setup|Hardware reset menu command and restart. If that doesn't work, restart the computer.
S
Stacy FinleySep 12, 2025
Why does Neurosoft Diagnostic Equipment require Service Pack 1 for Windows XP?
- W
  wrighthollySep 12, 2025
  If you receive the message “Install Service Pack 1 for operation under Windows XP” while using the Neurosoft Diagnostic Equipment, it means that the version of Windows XP installed on your PC has errors causing improper operation of USB devices. Install Windows XP Service Pack 1 or a later version of Windows.
