GB
│
19 ■
NMD 3.7 A1
CAUTION – PROPERTY DAMAGE!
► Charge the appliance only with the supplied charger.
► The oral irrigator may only be used with cold or
warm water. Do not use any chemical substances or
other solutions.
Set-up/wall bracket
NOTE
► The charger may only be operated free-standing if used in dry rooms.
Place the charger on a flat surface.
► In damp rooms, especially in the vicinity of water (bath), the charger
must be firmly fixed to the wall to protect it from falling into water.
1) Make sure that there are no electric cables, wires or pipes running
behind the wall surface where you plan to hang the charger .
2) Mark two drill holes on the wall 3.2cm apart and drill the marked
holes with a 5mm bit. Check to ensure that there is a mains power
socket in the immediate vicinity.
3) Push the supplied wall plugs into the holes and screw in the screws so
that the screw heads and around 3mm of the neck of the screws still
protrude from the hole.
4) Feed the cable through one of the recesses on the side of the charger ,
depending on which side the plug socket is located.
5) Push the charger onto the screws so that the screws protrude through
the holes on the charger . Then push the charger downwards so
that the screws slide into the rails and the charger sits firmly.
