NEW ENERGY NE-B345/100E User Manual

5
III. Main introduction of product
1. Detail parameters
Item DC Inverter instant heating heat pump
Model NE-B245/100E NE-B345/100E
Level of security IPX4
Electric shock protection grade Ⅰ
Rated power 220V～50Hz/60Hz
Rated output water volume 245L/h 345L/h
Tank volume 80L 80L
Rated heating capacity 7200W 11100W
Rated input power/ current 1670W/7.7A 2640W/12A
Heating capacity range 3000-8500W 5000-12400W
Input power 600-1750W 1000-3200W
Max input power/ current 2100W/9.8A 3200W/14.6A
Refrigerant/ injection volume R410A/1500g R410A/2650g
Rated water temp 55℃ 55℃
Max water temp
60℃ 60℃
Unit weight 75kg 110kg
Noise ≤50dB(A) ≤50dB(A)
Tank working pressure ≤0.8MPa ≤0.8MPa
Max allowable pressure of heat exchanger 4.2MPa 4.4MPa
Max allowable pressure of high/low pressure 4.2MPa 4.4MPa
Power line install standard ≥3×2.5mm2 ≥3×2.5mm2
