New Focus 100X - Page 17

DETECTOR CHARACTERISTICS
17
Fig 3. Responsivity vs. wavelength for a) Models 100X and b) Models
101X and 102X.
0.0
0.2
0.4
Responsivity
increases
from 0–0.42 A/W
over the range of
950–970 nm.
Wavelength, nm
400 600 800 1000 1200 1400 1600 1800
Responsivity, A/W
a
b
