DETECTOR CHARACTERISTICS
Model # 1001(1004) 1002(1006) 1011(1014) 1021(1024)
Wavelength Range 400-900 nm 400-900 nm 950-1650 nm 950-1650 nm
Max. Full Width at
Half Maximum
• • •
12 ps
Min. 3-dB Bandwidth
(Electrical)
35 GHz 50 GHz 40 GHz
•
Conversion Gain
at Peak
λλ
6.6 V/W 5 V/W 10 V/W 10 V/W
Responsivity
at Peak
λλ
0.2 A/W 0.2 A/W 0.4 A/W 0.4 A/W
Output Impedance
100 Ω 50 Ω 50 Ω 50 Ω
Min. NEP 70 pW/√Hz 90 pW/√Hz 45 pW/√Hz 45 pW/√Hz
cw Saturation
Power
5 mW 5 mW 1 mW 1 mW
Max. Pulse Power 200 mW 200 mW 100 mW 100 mW
Detector Material GaAs GaAs InGaAs InGaAs
Detector Type Schottky Schottky Schottky Schottky
Detector Diameter
12 µm 12 µm 12 µm 12 µm
Power
Requirements
9-V battery 9-V battery 9-V battery 9-V battery
Optical Input
(single mode fiber)
ST(FC) ST(FC) ST(FC) ST(FC)
Electrical Output Wiltron K Wiltron V Wiltron K Wiltron K
Bias Monitor:
DC Gain
1 mV/µA 1 mV/µA 1 mV/µA 1 mV/µA
DC Offset <10 mV <10 mV <10 mV <10 mV
Output Impedance
1 kΩ 1 kΩ 1 kΩ 1 kΩ
Bandwidth 50 kHz 50 kHz 50 kHz 50 kHz
