● OVERALL DIMENSIONS OF A STD COMPLETE MACHINE ON A TRAILER
● OVERALL DIMENSIONS OF WITHOUT ARM AND BUCKET
● OVERALL DIMENSIONS OF WITHOUT BOOM, ARM AND BUCKET
Combination
Type
A : Shoe width
mm (ft-in)
L : Length
mm (ft-in)
H : Height
mm (ft-in)
W : Width
mm (ft-in)
Weight
kg (lbs)
STD 600 (24″) 6,510 (21′4″) 2,740 (8′12″) 2,590 (8′6″) 12,720 (28,000)
LC 600 (24
″
) 6,590 (21
′
7
″
) 2,940 (9
′
8
″
) 2,840 (9
′
4
″
) 12,920 (28,500)
Without
Arm and Bucket
L 800 (32″) 6,620 (21′9″) ↑ ↑ 14,920 (32,900)
Combination
Type A : Shoe width
mm (ft-in)
L : Length
mm (ft-in)
H : Height
mm (ft-in)
W : Width
mm (ft-in)
Weight
kg (lbs)
STD 600 (24
″
) 3,570 (11
′
9
″
) 2,740 (8
′
12
″
) 2,590 (8
′
6
″
) 11,780 (26,000)
LC 600 (24″) 3,740 (12′3″) 2,940 (9′8″) 2,840 (9′4″) 11,980 (26,400)
Without
Arm and Bucket
L 800 (32
″
) 3,800 (12
′
6
″
)
↑ ↑
13,980 (30,800)
Model
Item
E135SR E135SR
LC
E135SR
L
Shoe & Width mm(ft-in) 600mm (24″) 2,590 (8′6″) 800mm (32″) 2,790
(9′2″)
Weight kg(lbs) 13,700 (30,200) 13,900 (30,600) 16,000 (35,300)
2-4
4. TRANSPORTATION DIMENSION AND WEIGHT
*
LC SPEC.
**
L SPEC.
**
L SPEC.
**
L SPEC.
