6-WORKINGOPERATIONS
Sidehydraulicvalves
OnlymodelswithrollbarsROPS
WARNING
Pressurizedsystem!
Beforedisconnectingthecouplers,youmust:
-lowertheconnectedattachments,
-stoptheengine,
-movethecontrolleversforwardandbackwardtodischargepressurefromthehydraulicsystem.
Failuretocomplycouldresultindeathorseriousinjury.
W0389A
WARNING
Pressurizeduidcanpenetratetheskinandcausesevereinjuries.
Keephandsandbodyawayfromanypressurizedleak.DONOTuseyourhandtocheckforleaks.Use
apieceofcardboardorpaper.Ifuidpenetratestheskin,seekmedicalattentionimmediately.
Failuretocomplycouldresultindeathorseriousinjury.
W0158A
Therearetwodistributors(1)gure2forttingsideor
frontimplements.
Thedistributorsarecontrolledbythelevers(2)and(3)
thatcommandthereardistributorswiththe"DIVERTER"
function,thatistosaybypressingthebutton(6).
Withconnectedimplementsworkingwiththeirownhy-
draulicmotor,connecttheoutletpipetothesocket(2)g-
ure2forrapidoildischarge.
Operation
Theleversshowninthegure,equippedwithbuttons
(6),canseparatelygovernanumberofimplements
connectedasdescribedbelow:
•
Movetheleversforwardstolowerorbackwardstoraise
theimplementsconnectedtothereardistributorswith-
outusingthebuttons(6).
•
Pressthebuttons(6)andmovetheleversforwardsto
lowerorbackwardstoraisetheimplementsconnected
tothesidedistributors.
MOIL13TR00452AA1
MOIL13TR00610AA2
6-12
