INSTALLATION INSTRUCTIONS - DUAL FUEL
LEVELLING YOUR COOKER
Place a spirit level on a baking sheet onto
an oven shelf.
ThecookeristtedwithLEVELLINGFEET.
Level your cooker to your desired height
using the levelling feet at the front and
rear of the cooker.
STABILITY BRACKET
Ifthecookeristtedwithaexiblecon-
nection,astabilitybracketshouldbetted
to engage in the back of the cooker. A
stability bracket can be bought from your
local supplier.
A stability bracket can be tted as
follows:
Place the cooker in position and draw a
PENCILLINElevelwiththefrontedge(2).
Mark the centre of the cooker to give a
CENTRELINE(3).
Remove the cooker and mark off 200mm
totherightofthecentreline(4)onthe
rear wall.
Measure from FLOOR LEVEL to the
ENGAGEMENT EDGE where the stability
bracketwillrestandadd2mm(5).
Transfer this dimension to the rear wall
and secure the bracket to the wall at this
height(6)usingthetwooffcentreholes
in the single bracket.
