Newage VersaRac - Parts Supplied; Items Required

2
Parts Supplied
Unpacking
• Begin by placing the package on a covered at surface.
• Remove all cardboard, foam packaging material and clear plastic bags.
• Dispose / recycle all packaging materials.
• Verify all the contents in the box and gather the required tools. See “Parts” and “Tools Needed” in the list below.
Hex Bolt
(5/16” dia x 3/4”)
Washer (5/16”)
Lock Nut
(5/16”)
8” Hanging
S-Hooks
Hex Bolt
(5/16” dia x 1/2”)
4” Hanging
S-Hooks
4” Post Mount
J-Hooks
2” Post Mount
J-Hooks
Part Description Quantity
Hanging S-Hooks
8in Hanging S-Hooks
2
4in Hanging S-Hooks
2
Post Mount J-Hooks
4in J-Hooks
2
2in J-Hooks
4
Hanging Bar Assemblies
Clothes Bar C Chanel
2
Drop Bar C Chanel
4
Grid Clip Bottom
4
Grid Clip Top
4
Hardware
5/16” dia x 1/2” Hex Bolt
4
5/16” dia x 3/4” Hex Bolt
4
5/16” Nylon Lock Nut
4
5/16” Washers
8
Grid Clip
Top
Grid Clip
Bottom
Drop Bar
C-Channel
Clothes Bar
C-Channel
VersaRac
Adjustable Wrench
Ladder
1/2” Socket Driver
Wrench
Items Required
