SECTION 7—PARTS BREAKDOWN
7.2 - Parts list for R4000CV/R5000CV
Item no. Description
Part No.
1
Front panel Bridge handle (2 per machine)
Lid Bridge handle (2 per machine)
M01393
M01084
2 24mm diameter knob M00464A
3 20mm diameter knob (2 per machine) M00033A
4 On/Off switch M70069A
5 Remote socket assembly M90762
6 70/90 panel mount Dix socket (2 per machine) M09916
7 Mains Switch — 3 phase power M70071
8 Filter Diac assembly M91123
9
Fuse holder
Fuse 3.15A slow blow, 32 x 6.3mm ceramic body
M01088/89
M00020A
10
Fuse holder
Fuse 6.3A slow blow, 20 x 5mm glass body
M00273
M00379
11 Soft start resistor assembly M90765
12 Auxiliary transformer M01408
13 Soft start relay M70026
14 Diode bridge M60057
15
Control PCB
R4000CV
R5000CV
M90744-R4000CV
M90744-R5000CV
16
IGBT (2 per machine)
R4000CV
R5000CV
M60245
M60229
17 IGBT gate drive assembly (1 per machine) M90843
18
Display PCB
R4000CV
R5000CV
M90771-R4000CV
M90771-R5000CV
19 Current transducer M60112
20 Capacitor Assembly M90456
21
Main inductor (Quote serial number of the machine when ordering for correct part)
R4000CV
R4000CV
R5000CV
R5000CV
M01094
M10105
M01094
M10106
22
Current transformer M01083
23
Main transformer ( Quote serial number of the machine when ordering for correct part)
R4000CV
R4000CV
R5000CV
R5000CV
M01093
M10102
M00878
M10103
24 De-coupling capacitor M90818
25 Diode module (4 per machine) M60121
26 Cooling fan (2 per machine) M00371
27 Rear Filter grill assembly M91157
When ordering spare components please quote the serial number of the unit for which the parts are intended.
