10.0 Free wheel mode
The motors of the wheelchair are equipped with brakes that prevent the wheelchair from rolling without control when the command is in the off
position. To push the wheelchair by hand, these brakes must be disengaged.
Note: motors must be disengaged by an attendant and not by the user! This ensures that the motors are disengaged only in the presence of an
atendant to secure the wheelchair and prevent it from rolling accidentally.
On each motor is located a red clutch lever to engage and disengage the respective motor.
Disengage the motor :
1. Turn off the power
2. Rotate the redclutch lever (1) in the vertical position. The motor is disengaged.
Note: If the release is difficult to make, lightly push the MAGIX forward or backward to remove the
pressure exerted on the mechanism.
Engage the motor:
Rotate the red clutch lever (1) in the horizontal position, the motor is engaged.
Note: For driving, both engines must be engaged.
Caution:
When the motors are disengaged the brakes are inactive. There is a danger that the wheelchair to
move by itself, especially on sloping ground! Always engage the motors when the wheelchair is stopped!
