Newskill Belenor Pro - Step 2: Install Connecting Rod; Step 3: Mount Side Bracket

2
• Install the connecting rod on the column as is shown in the picture.
• Respectively, line up the holes on both ends of the connecting rod and
the holes on the L shape metal of the columns.
• Tighten the bolts.
Install the connecting rod
Mounting the side bracket on each
side of the column.
7
M6*12 Bolt
X8
NOTE: Avoid excessive tightening bolts
NOTE: Avoid excessive tightening bolts
Side bracket
3
3
7
M6*12 Bolt
X4
EN
