Section 1 QUICKSTART
This section explains how to connect and configure your NewTek TCMI4KUHD device. It
also explains how to update, and where you can find additional NDI
®
software to extend
your workflow. After completing this section, you’ll be ready to begin using your device.
This document briefly describes how to prepare your new NewTek™ TCMI4KUHD device for use. Please note
that more detailed information is provided in the next chapter.
Step 1 – Connecting Your TCMI4KUHD Input Adapter
FIGURE 1
1. Using a CAT-5 (or better) Ethernet cable, connect the TCMI4KUHD device to one of the four PoE
(Power over Ethernet) RJ-49 connectors labeled NDI1-4 on the rear of your TriCaster TC Mini.
Step 2 – Access the Device Webpage
2. Open the Input Configuration panel for the TriCaster Switcher input you intend to connect this
device to. To do so, right-click on either a Switcher button or the input’s monitor viewport and
select Configure in the context menu.
FIGURE 2
3. Click the Source menu at upper-left in the input tab to view available sources.

NewTek TriCaster TC Mini TCMI4KUHD Specifications

General

Brand	NewTek
Model	TriCaster TC Mini TCMI4KUHD
Category	Adapter
Language	English
