What to do if one side of the image is blurred on my Nexcope NIB600 Microscope?
If one side of the image appears blurred on your Nexcope Microscope, it might be caused by the condenser not being properly centered. Use the centering screw to center the condenser. Also, ensure the nosepiece is correctly engaged and that the specimen is securely clamped with stage clips.
How to increase the brightness on a Nexcope NIB600 Microscope?
If the brightness is insufficient on your Nexcope Microscope, adjust the aperture diaphragm to allow more light to pass through.
What to do if I see dirt or dust in the field of view of my Nexcope NIB600?
If you see dirt or dust in the field of view of your Nexcope Microscope, the specimen may be placed reversely, so turn it over. It could also be due to a dirty lens (objective, condenser, eyepiece, or collector), so clean it. Also, the aperture diaphragm may be too large or too small, so adjust the aperture diaphragm. Finally, check the eyepiece for dirt or dust and clean it if necessary.
General| Type | Biological Microscope |
|---|---|
| Fine Division | 0.002mm |
| Stage | Double Layer Mechanical Stage |
| Magnification | 40x - 1000x |
| Observation Tube | 30° Inclined, 360° Rotatable |
| Eyepiece | WF10x/22mm |
| Nosepiece | Quintuple |
| Objectives | 4X, 10X, 40X, 100X (Oil) |
| Focusing | Coaxial Coarse and Fine Adjustment |
| Stage Size | 140mmX140mm |
| Moving Range | 75mmX50mm |
| Condenser | Abbe Condenser N.A. 1.25 with Iris Diaphragm |
| Illumination | LED |
| Voltage | 100-240V |
| Power Supply | AC Adapter |
| Weight | 7.5 kg |
