Nexo GEO M1210

MAINTENANCE
GEOM1210-I - GEOM1220-I Page 13 / 20
MAINTENANCE
Front panel disassembly
1
Remove the 4 screws (Tx25) to remove the grille.
2
Remove the front panel (10 screws Tx25)
3
To remove the HF Driver, unscrew the 4 nuts, and
remove it from the wave guide.
4
To remove the 12’’ driver, remove the 8 screws (Tx25).
Pay attention to the 4 spacers below the PMP.
Tightening torque for the 12’’: 3.5 Nm
