Next Level Racing ERS2 - Step 05: Remove GTTrack Seat Assembly; ERS2 SEAT INSTALL ON GTTRACK; Step 06: Align ERS2 Seat Sliders; Step 07: Secure Rear ERS2 Seat Sliders

PARTS:
•
• NIL
05
Remove the GTTrack Seat Assembly.
PARTS:
•
• 1 x ERS2 Seat Assembly
PARTS:
•
• 2 x M8 20mm Low Profile Bolts
•
• 2 x Steel Seat Spacers
Video Instruction: bit.ly/nlrbuild
13
06
Align the ERS2 Seat Slider mounting holes with the threaded inserts on the GTTrack frame.
07
Slide the ERS2 Seat rails all the way back to access the most rear slotted holes on the Seat Sliders.
Align the Rear Seat Slider holes with the Steel Seat Spacers. Bolt through and secure with 2 x M8 Low
Profile Bolts.
ERS2 SEAT INSTALL
Note: Hand tighten bolts to help
align the front seat rail holes on the
cockpit in STEP 09
Use most rear
slotted holes
on the Seat
Sliders
Use middle
holes on the
Seat Sliders
