Next Level Racing ES1 - For Set Up With Universal Seat Bracket; Bolt Universal Seat Bracket to Seat; Feed Supplied Seat Harness Through Holes Shown & Bolt to Seat; Completed Seat Ready to Install on Your Cockpit

6 7
support@nextlevelracing.com
Video Instruction: bit.ly/nlrbuild
1.0
2.0
3.0
BOLT UNIVERSAL SEAT BRACKET TO SEAT
FEED SUPPLIED SEAT HARNESS THROUGH HOLES SHOWN & BOLT TO SEAT
COMPLETED SEAT READY TO INSTALL ON YOUR COCKPIT
REPEAT
ON OTHER
SIDE
2 X 20MM M8 BOLTS
2 X WASHER
REPEAT
ON OTHER
SIDE
FOR SET UP WITH
UNIVERSAL SEAT BRACKET
FOR BOTTOM
MOUNT OPTION GO
TO PAGE 8
2 X 20MM M8 BOLTS
2 X WASHER
