PARTS:
• • 1 x Front Frame and Pedal Plate
• • 6 x M8 20mm Socket Head Bolts
• • 6 x M8 Washers
PARTS:
• • 4 x Leveling Feet
PARTS:
• • 1 x Wheel Plate
• • 4 x M8 20mm Socket Head Bolts
• • 4 x M8 Washers
• • 2 x M8 Flange Nuts
8
support@nextlevelracing.com
A) Place Wheel Plate onto Support Plate so the mounting holes align.
B) Secure in place using M8 20mm Bolts, Washers and Flange Nuts.
02
Lay Front Frame on side. Install Leveling Feet into the positions on bottom of Frame. Recommended to
lay down on carpet or packaging to protect floors.
01
A) Unfold Front Frame into upright position.
B) Secure in place with M8 20mm Bolts and Washers.
03
B)
B)
A)
A)
Repeat
on Other
Side
Make
sure nuts
are in
place!
To Next Page
