Next Level Racing VICTORY - Page 9

PARTS:
• • 1 x Left and Right Seat Frame
• • 1 x M8 20mm Socket Head Bolts
• • 1 x M8 50mm Socket Head Bolts
• • 2 x M8 Washers
• • 1 x M8 Flange Nut
PARTS:
• • 2 x Leveling Feet
PARTS:
• • 8 x M8 20mm Socket Head Bolts
• • 8 x M8 Washers
9
Video Instruction: bit.ly/nlrbuild
A) Slot the Seat Frame Assembly onto the Front Frame Assembly so the mounting holes align.
B) Secure in place using M8 20mm Bolts, and Washers.
05
Lay Seat Frame on side. Install Leveling Feet into the positions on bottom of Frame. Recommended to
lay down on carpet or packaging to protect floors.
04
A) Slot the Right Seat Frame onto the Left Seat Frame so that the mounting holes align.
B) Secure in place with M8 Bolts, Washers and Flange Nut.
06
B)
B)
A)
A)
Make
sure nuts
are in
place!
Repeat
on Other
Side
