F-GT SIMULATOR COCKPIT
Step 10: GT ASSEMBLY
1.
2 X 60MM BOLTS.
Repeat both sides.
*Once you are happy with the
position tighten as much as possible
to ensure wheel support is strong
and rigid
2. Insert Wheel Support Bars.
Use 2 X 16MM BOLTS on each side
to adjust height.
3. 2 X 50MM BOLTS.
Repeat both sides.
WHEEL PLATE
PEDAL PLATE
4. Attach GT SEAT
SUPPORTS to last holes
using 2 X 60MM BOLTS.
Repeat both sides.
5. Attach PEDAL PLATE to
frame using 1 X 16MM BOLT.
Repeat both sides.
