Nextech LA9038 - Technical Specifications

17
LA9038 SPECIFICATIONS:
Working Voltage 9-40V DC
Communicate
Network
2G GSM / 3G
WCDMA / 4G LTE
2/3/4G Module (Can
be Customized)
EC25-EC (Quectel) 2G GSM Band
B3(1800 MHz)/
B8(900 MHz)
3G WCDMA Band
B1(2100 MHz)/
B8(900 MHz)
4G LTE-FDD Band
B1/B3/B7/B8/B20/
B28A
2/3/4G & GPS
Antenna
Internal & Internal GNSS Module GPS
Locate precision 5-10 Meters GPS Hot Start Time 1 second average
GPS Cold Start Time 36 seconds average
Moving Tracking
Current
<100mA /12V
Stop Standby
Online Current
< 15 mA /12V
Stop Standby
Current
< 5 mA /12V
CAN BUS Channel 2 Channels
Backup Battery
Capacity
100mAh (Polymer)
Battery Recharging
Current
<100mA 5V
Working
Temperature
-20 0C to +55 0C
Absolute Working
Temperature
-40 0C to +80 0C
Storage
Temperature
-40 0C to +80 0C
