Nexus 21 L-50s - Page 9

9
Step 5: Slide the Column Clamp Base behind the Lift Column and line the holes up with the holes on the
Column Clamp Extension.
Step 4: Slide the Column Clamp Extension around
the front of the Lift Column and place it right below
the slots located on the left and right side of the Lift
Column.
Step 3: Fasten the Base Mount to both the bottom and
rear panel of the enclosure using (8) #10 x ¾” THWS
Step 6: Fasten the two brackets against the rear panel
of the enclosure using (2) #10 x ¾” THWS
