Maintenance and inspection schedule
If the boat does not accumulate the hours indicated below within 3 months, the frequency is
every 3:rd month.
Warning !
Failure to rectify any faulty conditions discovered as a result of the inspection could cause
sudden loss of Autopilot control, with consequential danger. It is recommended that all
items referenced in the following table be inspected before commencing any cruise.
Type Equipment: Check for: Remedy: Inspection
Frequency:
Mechanical Linear drive Corrosion Replace or Repair
4 Specifications
Type of Pumpt: Reversible gear pump.
Total length at mid stroke: 728 mm
Height: 125.6mm
Width: 142.7mm
Maximum stroke: 254 mm
Distance from centre of mounting
plate to tiller bolt at mid stroke: 505mm
Tiller bolt diameter 12mm
Mounting plate size 100x100 mm
Mounting screws 4x9mm Ø at 76mm centres
Lead length 1000mm
Temperature range -20ºC to +55 C
Supply voltage 12V (10-16V)
Enclosure IP44 (splash proof for under deck installation)
Peak thrust: 500kg
Average power consumption: 3 - 5 A ca 36 Watts (at 12V)
Warranty period: 2 years, see separate conditions
CE approval: The product conforms to the EMC requirements for immunity and emission
according to EN 5008-1 and EN 55022
