nfortec DRACO X - Technical Specifications

460mm
231mm
486mm
TECHNICAL SPECIFICATIONS
EN
MODEL DRACO X
DIMENSIONS (L x W x H) 460mm(L)x231mm(W)x486mm(H)
WEIGHT 8,7kg
MATERIAL Steel 0,7mm SPCC, tempered glass
FANS LOCATION
"Front: 3x 120mm
3x 140mm (3x A-RGB included)"
"Rear: 1x 120mm (1x A-RGB included)
1x 140mm"
"Top: 3x 120mm
2x 140mm"
PSU: 1x 120mm
Front: 120mm/240mm/360mm
WATER COOLING Rear: 120mm
Top: 120mm/240mm/360mm
DRIVE BAYS 3x 2,5" + 2x 3,5"
EXPANSION SLOTS x7 / x2 (vertical switch plate)
FRONT I/O
USB 3.0 x2
USB 2.0 x1
USB-C x1
Headphone/Microfone x1
Power/Reset
LED
1x Front
DUST FILTER 1x Top
1x Bottom
MOTHERBOARD TYPE E-ATX,ATX, MicroATX, ITX
POWER SUPPLY ATX up to 200mm (not included) bottom position
VGA (GPU) Up to 380mm (not included)
CPU COOLER Up to 175mm (not included)
CABLE MANAGEMENT 27mm
