Niagara 58145 - Parts List and Diagram

Page 7For technical questions, please call 1-888-866-5797.Item 58145
Parts List and Diagram
Part Description Qty
1 Nozzle 1
2 O-Ring 1
3 Diverter 1
4 Curved Connector 1
5 Wand Nut 2
6 Handle Connector 1
7 Handle Connector Nut 1
8 Seal 1
9 Piston Rod 1
10 O-Ring 1
11 O-Ring 1
12 Spring 1
13 Seal 1
14 Handle 1
15 Handle Nut 1
Part Description Qty
16 Hose 1
17 Wand 1
18 Trigger 1
19 Chock Plug 1
20 Outlet Tube 1
21 Outlet Filter 1
22 Outlet Nut 1
23 Tank 1
24 Pump Handle 1
25 O-Ring 1
26 Piston Cylinder 1
27 Bottom Stopper Plug 1
28 Piston Cylinder Nut 1
29 Piston Head 1
30 O-Ring 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
