Niagara JACE-9000 User Manual

• dual RS485
The controller supports up to four (4) opon modules. See “Opon module and capacity consideraons.”
Remote I/O expansion modules are supported by the RS485 connecon to the controller. See “RS485
wiring.”
WPM-8000
This is a wall-mount, Class2 Universal AC power adapter. The WPM-8000 supplies 24Vdc to a cable with a
barrel-connector plug.
Related Links
• Items included with the controller
• Material and tools requirements
• Opon module and capacity consideraons
• Precauons
• Inserng or removing the microSD card
Items included with the controller
The following items are also supplied with the JACE-9000 (15885) controller.
• MicroSD card in a plasc case (oponal for Beta release)
• Two 3-posion RS485 connector plugs
• One 2-posion power connector plug
• Grounding wire
• JACE-9000 Controller (15885) Quick Start Install Guide
Related Links
• General informaon (Parent Topic)
Material and tools requirements
The following material and tools are needed.
Power source
• UL listed, Class 2, 24Vac transformer, rated at minimum of 24Va. A dedicated transformer is
required (cannot power addional equipment), or
• UL listed Class 2 or LPS 24Vdc power supply, capable of supplying at least 1A (24W), or
• WPM-8000 wall-mount AC power adapter with barrel connector plug.
Mounng
• DIN rail, type NS35/7.5 (35mm x 7.5mm)
• DIN rail end-clips (stop clips)
• Suitable tools, fasteners, and accessories for mounng.
The controller can also be panel mounted.
5
General informaon
