HE.13631 © 05/2010
PC-20M
5
US
Instruction Manual
3. Remarks with respect to the intended use
3.1 Operation of the tool
The pressing cycle is started by actuating the trigger (page 1, pic. 1.7). The pressing cycle is characterized by the
closing motion of the jaws. Due to the linear movement of the rollers on the piston the jaws close scissors like.
Attention
A necessary condition for a permanently leak-free connection is that the pressing cycle has to be completed
and the jaws are closed.
Attention
The pressing process can be interrupted at any moment by releasing the trigger.
Attention
The assembly of gas pipes in gas distribution lines is prohibited unless the system provider gives an explicit
permission to use this tool on special gas fi ttings.
Attention
The user has to check by optical means whether the pressing jaws are completely closed.
Attention
If a pressing cycle has been interrupted the fi tting has to be either dismantled or pressed a second time.
Attention
Do not operate the tool without jaws and keep your hands away from the pressing tool head when
pressing.
Attention
Before changing the pressing jaws, remove battery to avoid unintentional operation.
Attention
Keep your hands away from the pressing tool head when pressing.
