HE.13631 © 05/2010
PC-20M
7
US
Instruction Manual
3.4 Service and maintenance instructions
The reliable performance of the tool is dependent on careful treatment and service. This represents an important
condition to ensure a lasting connection. For optimal performance, the tool should be maintained and serviced re-
gularly.
We would like to draw your attention to the following points:
1. The electric-hydraulic pressing unit should be cleaned and dried after each use before being put into the carrying
case.
2. In order to ensure the proper functioning of the machine, the pressing tool should be returned to an Authorized Ser-
vice Center (ASC) after the red LED indicates Service (after 10.000 pressing cycles) or once every year, whichever
occurs fi rst.
3. The battery as well as the charging unit must be protected against humidity and foreign objects.
4. The bolt joins, the rollers and their guides as well as the moveable parts of the pressing jaw must be oiled regularly
in small amounts.
5. Check through test compressions or have an ASC check the tool and pressing jaws regularly for proper function.
6. Keep pressing jaws clean. Remove dirt or any build up with a brush.
In order to avoid possible malfunctions, we offer you a manufacturer service consisting (see ASC) of disassembly,
cleaning, exchange of possibly worn out parts assembly and fi nal control. Only a clean and properly functioning pres-
sing tool can, over time, ensure a leak-free connection.
Within the determined use of the tool only the pressing jaws (page I, pic. 1.8) are permitted to be changed by the
installer.
Attention
Do not damage the seal of the tool. If the seal is broken the warranty is invalid.
