52
Cut away the punched metal cover in the rear panel
and hang the rear panel over the connecting flue pipe.
Connect the two ends of the flue pipes with an elbow
joint and seal the connection with heat-resistant sealant.
Fit the chimney mantle by lowering it onto the locating pins on the sealing plate. Then fix the rear panel to the mantle. Finally,
lay the covering plate on top.
Pannkitt
Pannkitt
Important!
The installation must be approved by a qualified inspector before the stove is made ready for use.
Read through the lighting and operating instructions for the Handöl 20 series carefully before lighting the
stove for the first time.
GB
Heat-resistant sealant
Heat-resistant sealant
