Mechanical limit switch setting
Small itypes - 8 Contactor cam
8 white Additional limit switch 2 CLOSE
7 green Additional limit switch 2 OPEN
6 white Additional limit switch 1 CLOSE
5 green Additional limit switch 1 OPEN
4 red Safety limit switch CLOSE
3 white Limit switch CLOSE
2 red Safety limit switch OPEN
1 green Limit switch OPEN
Optional
}
6
Emergency release chain
Mechanical limit switches
7
Small types Large types
Mechanical limit switch setting
Large types - 7 Contactor cam
8a
7 white Additional limit switch 2 CLOSE
6 green Additional limit switch 2 OPEN
5 white Additional limit switch 1 CLOSE
4 red Safety limit switch CLOSE
3 white Limit switch CLOSE
2 red Safety limit switch OPEN
1 green Limit switch OPEN
Optional
}
