18 – Robus 600-1000
FUNCTION
Diagnosis 1 - IN
RADIO INPUTS (On / Off)
:
Channel 1
Channel 2
Channel 3
Channel 4
SERIAL RADIO INPUTS
BOARD KEYS:
no. 1
no. 2
no. 3
DIRECTION SELECTOR
INPUT STATUS
inp 1
inp 2
inp 3
inp alt
ALT CONFIGURATION
MOTOR 1 (On / Off):
Limit switch on opening
Limit switch on closing
MANOEUVRE THRESHOLD
:
DESCRIPTION
Indicates when radio receiver channel 1 is active.
Indicates when radio receiver channel 2 is active.
Indicates when radio receiver channel 3 is active.
Indicates when radio receiver channel 4 is active.
Indicates when the control unit receives a serial command via BusT4
from a radio receiver; these commands range from minimum 1 to
maximum 15.
Indicates when key 1 is pressed (= OPEN) on the control unit.
Indicates when key 2 is pressed (= STOP) on the control unit.
Indicates when key 3 is pressed (= CLOSE) on the control unit.
Indicates the operating status of the selector for the direction of a
manoeuvre performed by the application.
Indicates when input 1 is active.
Indicates when input 2 is active.
Indicates when input 3 is active.
Indicates when the alt input is active.
Indicates the type of connection on the alt terminal. Connection
types are: not configured; NC; NO; 1 8K2 resistive edge; 2 8K2 resis-
tive edges; 1 OSE optical edge; out of range.
Indicates when motor 1 reaches the maximum opening position.
Indicates when motor 1 reaches the maximum closing position.
Indicates the operating status of the manoeuvre limiter, expressed in
levels:
Level 1: OK;
This function enables the display of the operating status of all inputs and outputs present on the control unit. The functions of
the inputs and outputs are described in Table 4.
TABLE 4: input/output DIAGNOSTICS
inputs / outputs
DIAGNOSTICS
This parameter is expressed in seconds and can be set with a value from 0.1 to 10 sec.; the factory setting is 2 sec. This func-
tion enables programming on the Control unit of the required time interval to pass between the end of a Closing manoeuvre and
the start of an Opening manoeuvre.
This parameter is expressed in seconds and can be set with a value from 0.1 to 10 sec.; the factory setting is 2 sec. This func-
tion enables programming on the Control unit of the required time interval to pass between the end of a Closing manoeuvre and
the start of an Opening manoeuvre, when the suction cup is detached.
This parameter is expressed in seconds and can be set with a value from 0 to 250 seconds; the factory setting is 60 seconds.
This function enables programming of the required time for which the courtesy light remains lit both on the control unit and on
output 1 (flash).
courtesy light time
suction cup time
electric lock time
