ENGLISH – 23
PROGRAMMING PARAMETERS
Switch 7 Function Description
ON
Close immediately
after Photo (only if
set on Automatic
operating mode)
When set in Automatic mode, it holds the boom open only for the time required for vehicles or
pedestrians to pass through it; in fact, when the Photo safety devices have been cleared, the
manoeuvre stops and after 5 seconds a closing manoeuvre starts automatically, regardless of the Pause
time settings.
OFF Deactivated
Switch 8 Function Description
ON
Safety Photo also in
opening
The intervention of the safety device also causes an interruption to the manoeuvre during opening.
When set in Semi-automatic or Automatic modes, the opening manoeuvre starts again as soon as the
safety devices have been cleared.
OFF The intervention of the safety device causes an interruption to the closing manoeuvre.
Switches
9-10
Function Description
OFF-OFF OGI and CL
The OGI output (terminal 9) assumes the function of Open Gate Indicator: off when closed, ashes
fast when closing, ashes slowly when opening, constantly on when open.
The CL output (terminal 8) assumes the function of Courtesy Light: it remains constantly on for the
entire duration of the manoeuvre and for 1 minute subsequently.
ON-OFF
One-way trafc light
and CL
The OGI output (terminal 9) assumes the function of a one-way trafc light: in this mode a green light
can be applied to the output, which indicates that the way is clear when it is on.
Light off: indicates that the boom is closed or closing.
Light on: indicates that the boom is open or opening.
The CL output (terminal 8) assumes the function of Courtesy Light: it remains constantly on for the
entire duration of the manoeuvre and for 1 minute subsequently.
OFF-ON Alternate trafc light
Function for controlling the ow of vehicles in the two directions using controlled transit of the barrier
mechanism. A different opening control can be set for each trafc direction: SbS (Step-by-Step) to enter,
SbS 2 (input Open) to exit.
Two trafc lights with red and green signals must be installed and connected to the OGI (terminal 9) and
CL (terminal 8) outputs:
- with the SbS control, the OGI output is activated: green light going in and red light going out
- with the SbS 2 control, the CL output is activated: green light going out and red light going in.
Light off indicates that the boom is closed.
Green light indicates that the boom is open and the way is clear.
Red light indicates that the boom is open and the way is not clear.
Amber light (both lights on) indicates that the boom is closing or that the way is not monitored.
The OGI and CL outputs can control small lamps with 24 V c (total maximum of 10 W per output). If
you need to use lamps with higher wattage, you must use relays driven by outputs on the control unit
which in turn control the trafc lights.
see "Figure 42".
ON-ON
Oview
(Red/green trafc
light)
Function dened by Oview.
Red/green trafc light default:
Green light lit when the boom is open and stationary, off for all the other positions (Terminal 9).
Red light lit when the boom is closed and stationary, off for all the other positions (Terminal 8).
Switch 11 Function Description
ON
Discharge
Discharge is enabled both when opening and closing with times set in Oview.
This is useful for faster departures and impact tests.
OFF Discharge not enabled.
Switch 12 Function Description
ON
Oview
(Photo Test)
Function dened by Oview.
Photo Test default:
The 24 V output (terminal 7) performs the photo test function to verify the correct operation of the
photocells.
OFF Fixed 24 V output on terminal 7.
