38 – ENGLISH
&
&
Unlocking and manual movement
To unlock the device:
1. turn the key slot cover
2. insert the key (A) and turn it towards the left or right
WIDE S
A
WIDE M
WIDE L
A
63
3. the gate leaf can now be moved manually to the desired
position.
To lock the device:
1. turn the key (A) back to its initial position
2. remove the key.
3. remove the rubber cap on the opposite side of the cubicle
and insert the lock cylinder through the hole
4. from inside the cubicle, insert from bottom to top the
U-shaped spring to lock the lock cylinder
5. turn the key (A) back to its initial position
6. remove the key.
