Step 5：Insert #1 Monitor Holder into #2
Handlebar, and tighten and secure two #7
Screws and two #6 Washers to #2 Handlebar
with A:Allen Key with Phillips Screwdriver.
Step 6：Unscrew #13 L-Shaped Pull
Pin Knob in counter clockwise, insert
and slide #11 Seat Post to #14 Main
Frame, move #11 Seat Post upward
or downward to the desired position,
release #13 L-Shaped Pull Pin Knob
into an adjustment hole in #11 Seat
Post, and then tighten this knob in
clockwise, make sure the knob is
firmly engaged in an adjustment hole.
Put the #10 Seat onto #11 Seat Post,
secure the bolts underneath the seat
with B: Open-end Wrench 14-15.
9
B
To Next Page
