Part # M017879450000 REV. July 1, 2011
ECOTECH EZ
TM
Variable Speed Motor/Control
WARNING
!
HIGH
VOLTAGE
DANGER
High voltage and
rotating parts could
cause serious or
fatal injury. Safe
installation, operation
and maintenance must be performed by qualied
personnel. Familiarization with and adherence to the
National Electric Code, NFPA (National Fire Protection
Association) standards and local codes is required.
It is important to observe safety precautions to protect
personnel from possible injury. Personnel should be
instructed for handling each of the following:
CAUTION
!
The motor shall only be used with the
supplied control.
CAUTION
!
The ECOTECH EZ
TM
motor/control
user interface is intended for swimming pool pump
applications only.
NOTICE
!
When unpacking the unit, verify all
motor, control, and user interface components are not
damaged. Make sure there are no visible loose wires
in the wiring/conduit box. Be careful lifting the motor/
control from the box. Act with care and in accordance
with prescribed procedures in handling and lifting
this equipment. Inspect all components for damage.
Should there be damaged components, please return
the product to your place of purchase.
NOTICE
!
There is a small time delay before
the unit starts.
WARNING
!
The ECOTECH EZ
TM
Motor/Control
is controlled for an automatic start. Starting is controlled
by your program schedule or via user input through the
user interface mounted on top of the motor.
WARNING
!
In the case of a motor/control trip
condition, the motor/control may restart without warning.
See the Fault Condition section for details, page 24.
!
Avoid contact with energized circuits
or rotating parts.
HIGH
VOLTAGE
DANGER
!
Always disconnect electrical power
at the fuse box or circuit breaker before handling
electrical connections. Double check to be sure
Power is OFF, and that it cannot be turned on while
you are working on the equipment.
WARNING
!
Make sure the unit is electrically
grounded and proper electrical installation wiring and
controls are used consistent with local and national electric
codes. Refer to “National Electrical Code Handbook” &
NFPA No. 70. Employ qualied electricians. Insulate all
connections carefully to prevent grounding or short
circuits. Reinstall all conduit and terminal box covers.
CAUTION
!
To connect power to the motor/control
unit, refer to the connection diagram on the nameplate.
AC line power is connected via the motor/control conduit
box terminal board only.
WARNING
!
Insulate all connections carefully to
prevent grounding or short circuits. Reinstall all conduit
and terminal box covers! Do not force connections into
the conduit
!
A poor electrical connection can overheat
and cause terminal and/or terminal board failures.
Because of this possibility, wiring harness quick-connect
terminals should be regularly examined carefully for any
signs of physical deterioration or loose t to the terminals
on the motor/control terminal board. If there is evidence of
loose t or deterioration, quick-connect terminals should
be removed from the wiring harness and the harness
wires then connected directly to the motor/control terminal
board wiring terminals. Care shall be taken to ensure
connections are made to the proper terminals and that
adequate electrical clearances are maintained.
315612_MNJ26_VAR SPD_nonSRVS.indd 4 7/19/11 8:01 AM
