Troubleshooting
6-38 Manual # 42-02-7223 C1
Excessive Faults Warning, EXCESSIVE FLTS WARN
Description: Excessive number of faults detected. Generated when more than five faults that resulted in an
emergency, controlled or ASAP stop. The counter resets if the car makes ten normal runs without any faults.
Car Reaction: Car taken out of service; registered calls canceled. Car proceeds to next available floor; cycles
doors to let passengers out. At floor “Excessive Faults Shutdown” fault activated and car will remain shut
down until iBox Fault Reset button is pressed, Inspection is toggled or power to the controller is cycled.
Tro ubleshooting:
1. Check Event Log to see drive faults generated before fault triggered. Troubleshoot discovered faults.
Excessive Motor Field Feedback Fault, EXCESS MF FDBK FAULT
Description: Excessive current in motor field. Threshold set to 85% of forcing current for more than 4 sec-
onds. If fault is recurring, excessive faults will be generated and the motor field module will be disabled.
Car Reaction: Emergency Stop.
Troubleshooting: May be related to faulty motor field module, iBox, or invalid motor field calibration.
1. If excessive faults (fault) generated, module is disabled and should not be outputting voltage. If this is
not the case, there may be a problem with the motor field module.
2. Calibrate the motor field. During calibration, the current and voltage should start at their maximum value
and decrease as calibration proceeds. If this is not the case, there may be a problem with the iBox.
Excessive Relevels Fault, EXCESS RELEVELS FAULT
Description: The car has failed to relevel after ten attempts.
Car Reaction: Cancel all calls and shutdown. The doors are cycled and the car remains shutdown until the
fault is reset by pressing the iBox Fault Reset button, toggling Inspection or cycling power to the controller.
Tro ubleshooting:
1. Check for mechanical or other failure preventing proper releveling.
2. Adjust brake and motor control during releveling with a full load in the car.
Excessive Restarts Fault, EXCESS RESTARTS FAULT
Description: Car has attempted movement from same floor an excessive number of times. This fault is
issued after twenty-five attempts. The counter is reset if the car makes one successful run.
Car Reaction: Cancel all calls and shutdown. Doors cycle and car remains shutdown for five minutes after
first fault or until fault is reset by pressing iBox Fault Reset button, toggling Inspection or cycling power.
Tro ubleshooting:
1. Check for mechanical or other failure preventing car from moving away from floor the floor.
Excessive Restarts Warning
Description: The elevator has attempted to start movement from the same floor successively for an exces-
sive number of times. This fault is issued after ten attempts. The counter is reset if the car makes one suc-
cessful run.
Car Reaction: None.
Tro ubleshooting:
1. Check for mechanical or other failure preventing car from moving away from floor the floor.
Exercise Operation Activated, EXERCISE OPERATION
Description: The car has been idle for a predetermined user-defined time and is now performing a user-
defined number of Exercise operation runs.
Car Reaction: The car lowers to the bottom landing, then proceeds to the top landing and back down to the
bottom landing without cycling the doors. Moving the car to the top landing and then back down to the bot-
tom landing is considered one exercise run. The user defines the number of exercise runs.
Exercise Operation Deactivated
Description: The car has completed all of the exercise runs or Exercise operation has been terminated due to
change in mode of operation or calls being entered into the system.
Exercise Operation Fail
Description:
Car Reaction:
Table 6.3 iControl Messages
iControl Messages
