iControl Messages
Manual # 42-02-7223 C1 6-65
6
iControl DC
Rear Door Close Fault, REAR DOOR CLOSE FAULT
Description: One or more rear door failures to close detected. Controller will attempt to close doors as
defined by user parameters (door close protection timer and number of attempts) before declaring fault.
(iView Controller > Configuration > Car Operation > Doors).
Car Reaction: Doors will reopen fully. All car calls canceled and car removes itself from hall call service (hall
calls assigned to car canceled or reassigned). Close doors using constant pressure on rear door close button.
Tro ubleshooting:
1. Door closed status is determined by rear door close limit and rear door position monitor contact.
2. Check the wiring of these signals.
3. Check the door close protection timer and number of closing attempts on the Operation/Doors tab.
Rear Door Close Fault Recovery Failure, R DR CLS FLT REC FAIL
Description: Door Close Fault Recovery timer starts when Door Close Fault generated. When timer expires,
Door Close Fault cleared to allow doors to again attempt to close (see Rear Door Close Fault). Repeats the
number of times specified by Door Close Fault Recovery Attempts parameter. If doors have failed to close
when number of attempts equals recovery attempts, Rear Door Close Fault Recovery Failure generated.
Car Reaction: Car is not allowed to run until a mode change is detected or doors are successfully closed via
constant pressure on Door Close Button.
Tro ubleshooting:
1. Door closed status is determined by rear door close limit and rear door position monitor contact. Check
wiring of these signals.
2. Check door close protection timer and number of closing attempts on the Car Operation - Doors tab.
Rear Door Close Time-out
Description: Rear door failure to close detected. Controller will attempt to close doors for period of time
defined by Closing protection timer (Door Motor Protection Timers). If timer elapses prior to doors closing
fully, this event is generated.
Car Reaction: Doors reopen fully and again attempt to close.
Tro ubleshooting:
1. Door closed status determined by rear door close limit and rear door position monitor contact
2. Check the wiring of these signals.
3. Check the Closing protection timer (iView Controller > Configuration > Car Operation > Doors).
Rear Door Contact Fault, REAR DOOR CONTCT FLT
Description: Faulty rear door contact (gate switch, door lock) detected. This is detected when the doors are
in their fully open position and either the gate switch contact is closed or the doors appear to be locked.
Car Reaction: All car calls are canceled and the car removes itself from hall call service. The rear doors are
not allowed to close and the car is not allowed to run.
Tro ubleshooting:
1. Check the rear door gate switch and door lock contact at the floor at which the car is located.
2. Check associated wiring for these signals.
Rear Door Open Button Bypassed, REAR DOB BYPASSED
Description: The rear door open button has been continuously activated for a user-defined time and is now
bypassed according to the user defined setting. (iView Controller > Configuration > Car Operation > Doors).
Car Reaction: The rear door open button is rendered inoperative.
Tro ubleshooting:
1. Check the corresponding input: Rear Door - Open Button (Normally low).
2. The operation of the door open button can also be restored by setting the Door open button bypass
option to off (unchecked) (iView Controller > Configuration > Car Operation > Doors).
Table 6.3 iControl Messages
