About the iBox Front Panel
System status indicator LEDs and function control switches are on the iBox front panel. The
front panel also provides:
• LCD display and entry keypad (see page 7-2).
• Access to iBox Ethernet Port addresses (see page 7-8).
• System-level diagnostic LED display (see page 7-10).
• System function control switches (see page 7-11).
Front panel controls allow you to:
• Directly view and adjust iBox configurable parameters (see page 7-2).
• Quickly ascertain system status (see page 7-10).
• Access Controller mode and other function switches (see page 7-11).
