iView Windows and Tabs
42-02-7223 C1 8-27
8
iControl DC
Car Operation
(continued)
Elevator Recall Recall floor, call disposition, door operation, and override settings for car
on recall operation
Earthquake Counterweight displacement sensor enable/disable, and earthquake code
selection for car on earthquake operation.
EMS Emergency Medical Service settings (recall floor, switch, and doors etc.)
Emergency
Power
Includes recall, generator and door settings for car on Emergency Power
operation.
CFSS Commandeer for Special Services. Parameters determine car behavior
when operating in CFSS Recall and In-car modes
Flood
operation
Determines Flood operation floors, substitute Emergency Power and Fire
recall floors, and Flood operation bypass settings
Attendant
service
Set front and rear door operation parameters used during Attendant Ser-
vice operation.
Auto stop Parameters determine car behavior during Automatic Stop operation.
Sabbath
operation
Enable/disable, select floors and other parameters that determine car
behavior while on Sabbath operation.
Shuttle
Service
Allows a car to provide express service for a subset of the building’s
floors.
Heat Detectors Parameters determine car behavior when heat detectors are activated.
Jail Operation Provides special control over elevator use.
Passenger
Distancing
Allows elevator to pass up hall calls when the user-programmed number
of car calls is exceeded.
Destination
Based
Dispatching
General Enable DBD, set door operation, anti-nuisance and floor settings parame-
ters.
Fixtures Car assignment tone, hall fixtures, car fixtures, car ID display and floors
with hall fixtures.
Drive General Drive type selection, speed reference selection, speed reference configu-
ration, and system drive-related selections for drive.
Safety Speed reference and over-current settings.
Control Drive gain, current, PID, and error compensation settings.
Filters Drive notch and system filter settings.
Dampening Drive speed and current control settings.
Pretorque Pretorque enable/disable and option settings.
Calibration Drive offset settings.
Floor Heights Configurations Use to view the learned values for the floor heights.
Floor Offsets Use to view the learned values of the floor offsets.
General General Job information, car label, ID, simplex car and backup dispatcher options.
Floors Data Front and rear opening settings for all floors.
Car Call
Eligibility
Car Call eligibility settings for all floors. Default eligibility configurations to
be used during special modes of operation, e.g. Independent service.
I/O Board Configuration Graphical display and organization of controller and cartop I/O boards
including specific input and output assignment on connectors.
Configurable
outputs
Determines during which modes of operation the Door Enable Output,
Automatic Closing Output and/or Hall Door Button Output are disabled.
iBox
Configuration
IP information for iControl.
Load Weigher Load Weigher configuration and threshold settings.
Table 8.5 Controller - Configuration Tabs
Tab Sub-Tab Content
To Next Page
