Using iView
8-32 Manual # 42-02-7223 C1
Table 8.10 System - Configuration Tabs
Tab Sub-Tab Content
Emergency
Power
Use to indicate cars connected to each generator and define how switch-
ing to and from emergency power is handled.
System
Configuration
Building Floor definition and labeling. Car definition and labeling.
CFSS Definition of Commandeer For Special Services modes 1 and 2.
Dispatching Define system dispatching options and manually select dispatching con-
figurations
Hall Call
Eligibility
Define up to eight Hall call eligibility configurations.
Mode of
Operation
Define up to eight dispatching Mode of Operation configurations.
Parking Define up to eight Parking configurations
Parking
Eligibility
Define up to eight Parking Eligibility configurations.
Split Bank This capability is only available through the Central Dispatcher.
Management Controls Remote Monitoring Authorization and Local Dispatcher - Resend
system parameters command.
Destination
Based
Dispatching
Enable DBD, set general DBD parameters, Destination Input Device
parameters, Hallway configuration and special operations configuration
parameters.
Legacy Group
Interface
Select either Cross-cancellation or Cross-registration.
Security General Shows the status of System Security. Use these controls to configure car
and hall call restrictions for a simplex or swing car or car assigned to be
the backup or local dispatcher for a group.
Hall Calls
Car Calls
System I/O System Configuration of system input/output settings.
Bus Serial bus troubleshooting.
Timer Tables Use to configure timer tables to control system functions, e.g., Hall call
eligibility, Parking, Parking eligibility, Mode of operation, Security, and
User outputs 1 through 3.
Custom Timers Define up to 4 input/output pairs so that if the input is activated, the cor-
responding output will activate after the configured time elapses.
User Events Define User Events which, when assigned a hardware input, are logged on
the System Event Log when activated and deactivated.
Remote Outputs Configuration Define and configure up to 32 Remote Outputs which can be wired to any
input or other device as needed.
Trigger
Predictive Gongs Parameters determine the behavior of predictive gongs.
Table 8.11 System - Diagnostic Tabs
Tab Content
Event Log Display of recorded system events.
Network Diagnostics Controller and Remote Client network information.
DID Diagnostics Display information for each DID (Reader ID)
Dynamic Parking
Diagnostics
Displays percentages of hall calls from each floor, per elevator bank.
