Nidec MCE iBox - Page 429

System and LAN Ethernet
42-02-7223 C1 9-17
9
iControl DC
iBox – Car 13 192.168.191.33 “ “ “
iBox – Car 14 192.168.191.34 “ “ “
iBox – Car 15 192.168.191.35 “ “ “
iBox – Car 16 192.168.191.36 “ “ “
iBox – Car 17 192.168.191.37 “ “ “
iBox – Car 18 192.168.191.38 “ “ “
iBox – Car 19 192.168.191.39 “ “ “
iBox – Car 20 192.168.191.40 “ “ “
iView
192.168.191.103 –
192.168.191.104
““ “
iCue
192.168.191.203 –
192.168.191.204
““ “
Group 3 – LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.41 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.42 “ “ “
iBox – Car 3 192.168.191.43 “ “ “
iBox – Car 4 192.168.191.44 “ “ “
iBox – Car 5 192.168.191.45 “ “ “
iBox – Car 6 192.168.191.46 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.60 “ “ “
iView
192.168.191.105 –
192.168.191.106
““ “
iCue
192.168.191.205 –
192.168.191.206
““ “
Group 4 – LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.61 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.62 “ “ “
iBox – Car 3 192.168.191.63 “ “ “
iBox – Car 4 192.168.191.64 “ “ “
iBox – Car 5 192.168.191.65 “ “ “
iBox – Car 6 192.168.191.66 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.80 “ “ “
iView
192.168.191.107 –
192.168.191.108
““ “
iCue
192.168.191.207 –
192.168.191.208
““ “
Group 5 – LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.81 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.82 “ “ “
iBox – Car 3 192.168.191.83 “ “ “
iBox – Car 4 192.168.191.84 “ “ “
iBox – Car 5 192.168.191.85 “ “ “
iBox – Car 6 192.168.191.86 “ “ “
