Reference
9-18 Manual # 42-02-7223 C1
…… “ “ “
iBox – Car 20 192.168.191.100 “ “ “
iView
192.168.191.109 –
192.168.191.110
““ “
iCue
192.168.191.209 –
192.168.191.210
““ “
Group 6– LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.121 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.122 “ “ “
iBox – Car 3 192.168.191.123 “ “ “
iBox – Car 4 192.168.191.124 “ “ “
iBox – Car 5 192.168.191.125 “ “ “
iBox – Car 6 192.168.191.126 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.140 “ “ “
iView
192.168.191.111 –
192.168.191.112
““ “
iCue
192.168.191.211 –
192.168.191.212
““ “
Group 7– LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.141 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.142 “ “ “
iBox – Car 3 192.168.191.143 “ “ “
iBox – Car 4 192.168.191.144 “ “ “
iBox – Car 5 192.168.191.145 “ “ “
iBox – Car 6 192.168.191.146 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.160 “ “ “
iView
192.168.191.113 –
192.168.191.114
““ “
iCue
192.168.191.213 –
192.168.191.214
““ “
Group 8 – LAN Network (Blue cables)
IP Subnet Gateway DNS
iBox – Car 1 192.168.191.161 255.255.255.0 192.168.191.254 * 192.168.191.254 *
iBox – Car 2 192.168.191.162 “ “ “
iBox – Car 3 192.168.191.163 “ “ “
iBox – Car 4 192.168.191.164 “ “ “
iBox – Car 5 192.168.191.165 “ “ “
iBox – Car 6 192.168.191.166 “ “ “
…… “ “ “
iBox – Car 20 192.168.191.180 “ “ “
iView
192.168.191.115 –
192.168.191.116
““ “
iCue
192.168.191.215 –
192.168.191.216
““ “
