5 Measuring mode
Please change the measuring mode by Mode key.
Open mode Average mode Closing mode
㻌
Open
Mean Close
㻌
Open
㻹㼑㼍㼚㻌 㻯㼘㼛㼟㼑㻌
㻌
Open
Mean Close
Mode Mode
ᵬᶋᴾᵬᶋᴾᴾᵬᶋᴾ
Mode
5.1 Open Measuring Mode
Hold the peak value of torque for opening direction on measuring table.
Measuring cycle, 8 times/second
Display cycle, 8 times/second
Show the Torque in “real time” (Mean) until hold the peak value of opening direction.
Reset the peak hold by pressing Zero/RST key.
Mean Close
㻌
Open
Mean
ᴾ
Zero/RST
ᵬᶋᴾ
Close
Open
㻌
Peak hold reset
5.2 Average measuring mode
Show torque of measuring table in real time.
Display cycle choose at Function: 1 time/second, 2 times/second, 4 times/second, 8 times/second
Measuring time, Same as display cycle.
Zero set is done by pressing the Zero/RST key.
Mean Close
Open
Mean Close
Open
ᵬᶋᴾ
㻌
Zero/RST
Zero set
㻌
㻡㻌
