55
05-711
Read the complete manual before attempting installation and
activating the system.
1. DESCRIPTION
The 1-10V analog control 05-711 is designed for DIN rail mounting and
is 4U wide (71,5mm). The 1-10V analog control is suitable for switching
and controlling dimmable electronic control gear for fluorescent lighting,
compact fluorescent lighting or dimmable LED lighting. The appliance
has an analog 1-10V output and a switching capacity of 6A which is
used to switch the electronic control gear (ECG). The analog control
can switch a fluorescent load with a compensation of up to 140μF
and control up to 50mA.
You can choose from 3 control modes: 0-10V analog control, 1-button
control and 2-button control. The push button controls can be used
with or without memory.
The analog control is provided with a panic function. This allows the
lighting to be maximally controlled by means of a panic button (push
button/switch) as long as the function is activated, regardless of the
load condition. Depending on the selected operation mode, a light
atmosphere mode is available.
EN
