69
05-711
for Philips and OSRAM, this means a max. of approx. 160 ECG and
for Vossloh-Schwabe a max. of approx. 50 ECG.
- This appliance is only suitable for controlling appliances with a 1/10V
current control as described in European standard EN60929.
- If 230V (L and N) is connected to the inputs or to the 1-10V output,
this may have destructive consequences for the product. The appliance
is, however, protected against the inadvertent connection of only L or
N to the inputs of the 1-10V output.
7. TECHNICAL DATA
1/10V ANALOG CONTROL (05-711)
- Power supply
- mains supply 230V~ ± 10% 50Hz
- current consumption <2W
- Connection 0-10V
- analog input 0 to 10V DC
- Push button input (extra insulated with respect to 230V)
- number: 3 (without illumination)
- galvanically isolated; 1mA
- max distance: 100m; max. 30 in parallel per input
- Analog output (SELV with respect to 230V; basic insulation with respect
to control inputs)
- passive 1 to 10V DC/50mA
- Potentialfree relay output
- switching current: max. 6A for fluorescent load (compensated:
≤ 140μF)
EN
