Nikon 1 J3 Reference Manual

164
g
Check and optimize the camera image sensor and image proces-
sors if you notice unexpected bright spots in your pictures (note
that the camera comes with the sensor and processors already
optimized). Before performing pixel mapping as described
below, check that the battery is fully charged.
1
Attach a lens and lens cap.
Turn the camera off and attach a 1 NIKKOR lens. Do not
remove the lens cap.
2
Select Pixel mapping.
Turn the camera on, press G, and select Pixel mapping in
the setup menu.
3
Select Ye s .
Pixel mapping begins immediately. Note that other opera-
tions can not be performed while pixel mapping is in
progress. Do not turn the camera off or remove or disconnect
the power source until pixel mapping is complete.
4
Turn the camera off.
Turn the camera off when pixel mapping is complete.
View the current firmware version.
Pixel Mapping
Firmware Version

Nikon 1 J3 Specifications

General

Sensor	CMOS
Image Processor	EXPEED 3A
ISO Range	160-6400
Autofocus	Hybrid AF (Phase-detection/Contrast-detect AF)
Battery	EN-EL20 Rechargeable Li-ion Battery
Battery Life	Approx. 220 shots
Camera Type	Mirrorless Interchangeable Lens Camera
Lens Mount	Nikon 1 Mount
File Format	JPEG, RAW (NEF)
Movie File Format	MOV
Movie Video Compression	H.264/MPEG-4 AVC
Metering Method	Matrix, Center-weighted, Spot
Shutter Type	Electronic
Interface	USB 2.0
Sensor Size	13.2 mm x 8.8 mm
Video Resolution	1920 x 1080
Movie frame size and frame rate	640 x 240 (400 fps), 320 x 120 (1200 fps)
Screen	3.0-inch LCD, 921, 000 dots
Storage Media	SD/SDHC/SDXC
Dimensions	101mm x 60.5mm x 28.8mm
Focal Length	Varies with lens
Image Size (pixels)	4608 x 3072
Exposure Modes	Program Auto, Shutter-Priority Auto, Aperture-Priority Auto, Manual
Shutter Speed	1/16000 to 30 sec
HDMI Output	HDMI mini connector (Type C)
Continuous Shooting Speed	15 fps (with AF), 60 fps (fixed focus)
