Page #213 background imageLoading...
Page #213 background image
193
n
Eye-Fi cards cannot be
used with the write
protect switch in the
“lock” position.
Turn the camera off and slide the card
write-protect switch to the “write”
position.
173
Memory card is full.
You may be able to record additional
images if you reduce image quality or
size.
123
Delete unwanted images. 87
Insert another memory card. 14, 172
This memory card
cannot be used. Card
may be damaged;
insert a different card.
Use an approved card. 172
Format the card. If the problem per-
sists, the card may be damaged. Con-
tact a Nikon-authorized service
representative.
161
Insert a new memory card. 14, 172
Cannot create
additional folders on
memory card.
If the current folder is numbered 999 and
contains either 999 photographs or a
photograph numbered 9999, the shut-
ter-release button will be disabled and
no further photographs can be taken.
Choose
Ye s
for
Reset file numbering
and then either format the current mem-
ory card or insert a new memory card.
164
The movie-record
button cannot be used
in this mode.
The movie-record button can not be
used in best moment capture or
Motion Snapshot modes.
48, 61
Photographs cannot
be recorded in this
mode.
The shutter-release button can not be
used to take photographs while a
slow-motion movie is being recorded.
51
The capture
illuminator has been
used consecutively for
the maximum time
and has turned off.
The capture illuminator on the
optional SB-N5 flash unit turns off
automatically after extended use.
Remove your finger from the shutter-
release button for a short period.
74
Photographs cannot be
taken in shutter- priority
auto mode at a shutter
speed of “Bulb.
Choose a different shutter speed, or
select mode w.
35, 37
Message Solution 0

Table of Contents

Other manuals for Nikon 1 v2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon 1 v2 and is the answer not in the manual?

Nikon 1 v2 Specifications

General IconGeneral
Megapixel14.2 MP
Camera typeMILC
Sensor typeCMOS
Sensor formatCX
Image stabilizerNo
Total megapixels15.13 MP
Image sensor size- \
Image formats supportedJPG, RAW
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3072 pixels
Image sensor size (W x H)13.2 x 8.8 mm
Still image resolution(s)3:2:\\r 4608 x 3072\\r 3456 x 2304\\r 2304 x 1536
Optical zoom- x
Focal length range- mm
Lens mount interfaceNikon 1
Minimum aperture number-
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto focusing (AF) modesContinuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Matrix, Spot
ISO sensitivity160, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed30 s
Flash modesFill-in, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed1/250 s
Flash guide number5 m
Flash exposure correction-3EV - +1EV (1/3 EV step)
Power source typeBattery
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Resolution at capture speed640x240@400fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)921000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.47 \
USB version2.0
HDMI connector typeMini
Data networkNot supported
Eye relief18 mm
Scene modesClose-up (macro), Night landscape, Portrait, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceAuto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modesAperture priority, Auto, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Languages supportMulti
Camera file systemDCF, DPOF, Exif 2.3
Diopter adjustment (D-D)-3 - 2
Battery typeEN-EL21
Battery life (CIPA standard)310 shots
Product colorWhite
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth45.9 mm
Width107.8 mm
Height81.6 mm
Weight278 g
Weight (including battery)337 g
