Nikon D5200 Installation Manual

10
5. Connecting the device
DO NOT connect the camera (neither DC nor USB) when the xTex device is switched
on. This can cause serious damage to the xTex device.
• Connect the camera USB cable.
Nikon D5200 only:
(In case the cable is not already installed)
Connect the plug of the USB cable with the female connector of the USB extension
cable.
In case the cable is not already installed:
Connect one end of the USB cable with the USB port of the camera and the other end
with the USB port of the device.
• Connect the camera power cable.
Connect one end to the plug of the power connector and insert the special connector
to the jack of the device’s camera power supply.
The special connector has 4 pins and a groove at the bottom. Insert the plug fully into
the socket first, and then turn the knurled bezel clockwise.
• Connect the USB connector cable to the PC.
Connect the end of the cable to the jack on the unit and the other end to the PC.
Connect the power cord (Inlet plug) to the power connector of the device.
The device must be connected to a grounded, easily accessible AC outlet. Do not handle the
power plug with wet hands to prevent electric shock.
!
!

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
