Specifications
Type: Dach prism central focusing type
Model 8×30 10×30 8×42 10×42
Magnification (×) 8 10 8 10
Effective diameter of objective
lens (mm)
30 30 42 42
Angular field of view (real) (˚) 8.3 6.7 8.3 6.9
Angular field of view (apparent) (˚)*
60.3 60.7 60.3 62.2
Field of view at 1,000m/yds. (m/ft.)
145/435 117/351 145/435 121/362
Exit pupil (mm) 3.8 3.0 5.3 4.2
Brightness 14.4 9.0 28.1 17.6
Eye relief (mm) 15.1 15.8 17.1 16.5
Close focusing distance,
approx. (m/ft.)
2.0/6.6 2.0/6.6 2.5/8.2 2.5/8.2
Length (mm/in.) 119/4.7 119/4.7 142/5.6 142/5.6
Width (mm/in.) 125/4.9 125/4.9 130/5.1 130/5.1
Depth (mm/in.) 48/1.9 48/1.9 57/2.2 57/2.2
Weight (g/oz.) 465/16.4 470/16.6 670/23.6 680/24.0
Interpupillary distance
adjustment (mm/in.)
56-72/2.2-2.8 56-72/2.2-2.8 56-72/2.2-2.8 56-72/2.2-2.8
Waterproof structure Waterproof (up to 1m/3.3 ft. for 10 minutes), fogproof
* Apparent field of view is calculated based on the ISO14132-1:2002 standard
