Niles CS12V - Placement of the CS12 V; Table-top Placement; Wall-mount Placement

Figure 2: Table-top (on the floor or
shelf behind the equipment).
Figure 3
: Wall-mount (affixed to
the back of the equipment cabinet
or a nearby wall)
4
PLACEMENT OF THE CS12V
Place the CS12V conveniently close to the component it will be connected to. Generally, the
CS12V is placed in a concealed location because its indicator lights are only used during installa
-
tion. Placement possibilities include:
1. Table-top – on the floor or shelf behind the equipment Figure 2.
2. Wall-mount – affixed to the back of the equipment cabinet or a nearby wall Figure 3
.
(CONTINUED ON NEXT PAGE)
